Tube Angle Gusset
Tube Angle Gusset
Purpose :
Creates Tube Angle Gusset to different
combination. (Hollow Section, Angle and Rod).
Description:
This application creates a gusset
connection to different combination of secondary profile types such as rod,
hollow section and an angle. It has in built options to have connection plates
on the top or at the bottom and chamfer the corners of the plates. Seal plate
will be split if the tongue plate is extended. Multiple stiffeners can be added
to strengthen the connection.
Watch the second part : Tube Angle Gusset with full depth stiffener.
