Company Setup
Company Set Up
Investing in this technology is only worthwhile if you can leverage its full potential from the outset. Although the software does come with standard settings, it often requires customization to meet specific company standards and to make the files easily accessible. This can involve adjusting the configuration of initialization files, creating customized templates, and optimizing various aspects of the interface such as keyboard shortcuts and ribbons.To ensure your company is fully optimized and ready to go, we have developed a pre-defined and comprehensive set of localization options that cater to your unique requirements.The package includes a vast range of files, more than enough to cover any project. However, if you have any specific requirements, simply fill out the excel sheet and send it to us. We can complete the job in just 10 days, enabling you to hit the ground running and maximize your productivity. As an expert, I strongly advise taking advantage of this service to ensure your company's success with Tekla software.
Default Fabrication drawing settings are standardised to produce drawings by names. It increases editing time as we need separate settings for different profile types. For example, settings for I Section will be different to Hollow and C Sections. In model, we use different type of sections as Beams. Hence using default beam settings will not be right property and it requires editing your drawings. Whereas I have developed settings to create drawings by profile types. These will produce drawings with exclusive and appropriate settings based on the profile types. The only concern is the part or assembly name will not be displayed correctly as the drawing property does not read the model database.To resolve, we have developed Part Values to Drawing Fields application to copy model part name to the document manager.
Drawing Settings & Templates Design :
Single Part Drawing
Default Templates :
- Single Part Title Block
- Revision
- Company Logo
- Part Call Off
- Workshop Part List
- Single Part Phase Template
Templates With Option :
- Single Workshop in Assembly List
- Double Workshop in Assembly List
- Three Workshop in Assembly List
- Purlin Sheet
- Client Logo
- Sheet Size
- Revision Description / Drawing Stamp
Drawing Settings :
- Profile_Angle
- Profile_Channel
- Profile_Beam
- Profile_Column
- Profile_Hollow
- Profile_Cleat
- Profile_Plate
- Profile_Main_Plate
- Profile_Cold_Rolled
View Level Settings :
- View_Beam (No Center Line in Front View)
- View_Back_Reference ( No Center Line in views)
- View_Center_Line (Center Line In all views)
- View_Plate ( Front View Only)
- View_Cold_Rolled
Assembly Drawing
Default Templates :
- Title Block
- Revision
- Company Logo
- Assembly Call Off
- Metric Assembly Part List
- Phase Template
- Grid Template
Templates With Option :
- Workshop Bolt List
- Workshop Stud List
- Purlin Sheet
- Client Logo
- Sheet Size
- Revision Description / Drawing Stamp
- General Notes
Drawing Settings :
- Profile_Angle
- Profile_Channel
- Profile_Beam
- Profile_Column
- Profile_Hollow
- Profile_Main_Plate
- Profile_Cold_Rolled
View Level Settings :
- Assembly_View_Beam
- Assembly_ View _Back_Reference
- Assembly_ View _Center_Line
- Assembly_ View_LoosePart
- Assembly_ View _Cold_Rolled
Cast Unit Drawing
Default Templates :
- Title Block
- Revision
- Company Logo
- PC Info
- PC Surface Treatment
- PC CIP Call Off
- PC Panel Propping
Templates With Option :
- Revision Status / Drawing Stamp
- Client Logo
- Sheet Size
- Panel Notes
- Reinforcement
- Mesh Schedule
Drawing Settings :-
- Panel_Horizontal
- Panel_Vertical
- Cast Unit Drawings For Columns
- Cast Unit Drawings For Beams
View Level Settings :
- Panel Front View
- Panel Section View
- Panel Reinforcement View
General Arrangement
Default Templates :
- Title Block
- Revision
- Company Logo
- Client Logo
- Handrail List
- Revision Description / Drawing Stamp
- Erection Notes
- Project North
Templates With Option :
- Bundle List
- Cladding List
- Single Assembly List
- Double Assembly List
- Three Assembly List
- Single Member Schedule
- Double Member Schedule
- Three Member Schedule
Drawing Settings
- Set_GA
- Set_Elevation
- Set_Plan
- Set_Steel_Frame
- Set_Roof_Purlin
- Set_HD Bolt Plan
- Object level settings for drawing and View properties
View Level Settings :
- Detail View
- Section View
- View Elevation
- View Plan
- View Purlin
- HD Bolt Plan
- 3D View
Package Includes :
Initialization file
set up for firm folder and standard
variables
Filters for all most commonly
used names in the model. These filters are
available for selection, view, object
representation, organizer in
Model.
Objects.inp file for additional user
defined attributes at Project, Part and Drawing
Level.
Reports for Material Take Off and
IFA and IFC Pack.
Common Custom
Components
Organizer Property Settings
Useful Application downloaded from Tekla
Warehouse
Keyboard Shortcuts for Frequently
used tools
Bolt Catalog and Bolt
Assembly
Ribbon Customization (user
preference)
Organizing folder structure for
handling efficiently
Drawing Layout Files for A1, A2, A3 for Assembly, Precast and GA drawings. A3 and A4 for Single Part Drawings
Filters at Drawing and
View Level.
Object level settings for GA’s
are also included in the package.
Printer
settings with pen thickness and line width.
IBim
Applications:
Part Values to
Drawing Fields (1 Licence)
Tekla Excel Live
Link (1 Licence)
View Settings
Include :
Dimension, Scale,
Shortening, Part Mark, Bolt Mark, Part, Bolt,
Weld, Reinforcement.
